New Lathe Alignment Test Bar Shank Size 1MT, 2MT, 3MT, 4MT, 5MT, 6MT
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | SKYLARK |
| Model Year | 2023 |
LATHE ALIGNMENT TEST BAR SHANK SIZE 1MT, 2MT, 3MT, 4MT, 5MT, 6MTWHOLESALES LOT AVAILABLE THROUGH EBAY ONLYPRODUCT DETAILS:Shank Overall-Length Max. Run-Out Measuring cylinder diameter Length of cylindrical measuring surface 1MT 151mm (5-15/16”) 0.0002” 11mm 90mm 2MT 283mm (11-1/8”) 0.0002” 17mm 210mm 3MT 335mm (13-3/16”) 0.0002” 23mm 245mm 4MT 386mm (15-1/4”) 0.0002” 30.50mm 273mm 5MT 400mm (15-3/4") 0.0002” 6MT 507mm (19-7/8") 0.0002"Parallel Shank.- Overall Length- 272mm (10-3/4") Max Run-out- 0.0001" (Diameter of the bar 30mm)Re-align the tail-stock on your lathe to eliminate that slight taper when turning over a long distanceUseful for alignment test between centers as well as in morse taper spindlesManufactured from EN31 Alloy SteelRe-align the tail-stock on your lathe to eliminate that slight taper when turning over a long distanceUseful for alignment test between centers as well as in morse taper spindles
