Graymills IMV25-E 115/230V 1 Phase Replacement Immersion Coolant Pump 20 GPM
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | Graymills |
| MPN | IMV25-E |
Dependable economical Replacements for Coolant pumps commonly supplied as original equipment on machine tools.Immersion Pumps (IMV-Style)No bearings seals or packing are immersed in liquid making them ideal for pumping liquids containing fine contaminants. Suction Pumps (IMS-Style)They should not be used to circulate fluids containing fine contaminants. Not recommended for Applications requiring the circulation of liquids containing large amounts of foreign matter. With a maximum 2 ft. suction lift they may be mounted above liquid level as well as other locations remote from the tank.Features 3450 RPM sealed bearing motors. 1/4 HP - 1/4" flange mounting holes (diameter) and plastic impeller. Pump Body and volute are made from cast iron. Shaft made from carbon steel."E" ModelsMotor: 115/230V 60/50 Hz 1 PH "F" > Product SpecificationsProduct Specifications Brand Graymills Pump Type Immersion Model # IMV25-E Horsepower 1/4 HP Maximum Flow Rate 20 GPM Voltage 115/230V 60Hz 1 Phase Overall Length 14-3/16" Flange Dimensions 6-3/8" Flange Bolt Circle 6-1/4" Position Electrical Connect To Discharge 180° Intake & Discharge — Length of Pump 7" Discharge 1/2" Volute 4-3/4" Maximum Head_Feet of Water 32 Price Table Description Immersion Pump Weight 34 lbs. Country of Origin Import
