ER20(60) 1HP Power Head 750W Cutting/Boring/Milling Machine Tool Spindle Motor
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Model | ER20（60） |
| Country/Region Of Manufacture | China |
| Item Type | Spindle Head |
| Operating Speed | 6000RPM |
| Applied For | Drilling |
| Max. Power | 750W 1HP |
| Color | green |
| Dimension | 234*60*60mm |
| Center Height | 31mm |
| Run-out | 0.01mm |
| Shaft Head Size | ￠14×38mm |
| Drive | Belt Drive |
| MPN | Does Not Apply |
| Brand | Unbranded |
| Clamping Range | 2-13mm |
| Central Height | 31mm |
Specifications : Size: 234x60x60mm Axle head size: diameter 14mmx38mm Central Height: 32mm Run-out: 0.01mm Spindle: ER20 Speed: 5000~6000rpm Bearing: 7203*2, 6203*1, 6202*2 Max. Power: 0.75KW 750W 1HP Clamping range: 2-13mm Rising Temperature: within 25 Degree Celsius Spindle Material: 20CrmnTi, carburizing heat treatment 1. Shipping list 1PC ER20(60) Power Head 2. Specifications Model Drilling Drilling +Waterproof Drilling +High Speed Drilling +High Speed +Waterproof Angular Contact Boring Milling Angular Contact Boring Milling +Waterproof Overall size 234×60×60mm 234×60×60mm 234×60×60mm 234×60×60mm 234×60×60mm 234×60×60mm Shaft head size 14x38mm 14x38mm 14x38mm 14x38mm 14x38mm 14x38mm Central height 31mm 31mm 31mm 31mm 31mm 31mm Clamping range 2-13mm 2-13mm 2-13mm 2-13mm 2-13mm 2-13mm Run-out 0.01mm 0.01mm 0.01mm 0.01mm 0.01mm 0.01mm Speed 3000rpm 3000rpm 5000~8000rpm 5000~8000rpm 5000~6000rpm 5000~6000rpm Rising Temperature within 25 Degree Celsius within 25 Degree Celsius within 25 Degree Celsius within 25 Degree Celsius within 25 Degree Celsius within 25 Degree Celsius Spindle Material 20CrmnTi, carburizing heat treatment 20CrmnTi, carburizing heat treatment 20CrmnTi, carburizing heat treatment 20CrmnTi, carburizing heat treatment 20CrmnTi, carburizing heat treatment 20CrmnTi, carburizing heat treatment Bearing deep groove ball bearing deep groove ball bearing 7003*2, 6003*1, 6002*2 7003*2, 6003*1, 6002*2 7003*2, 6003*1, 6002*2 7003*2, 6003*1, 6002*2 application Drilling Cutting Machine Drilling Cutting Machine Drilling Cutting Machine Drilling Cutting Machine Boring Milling Cutting Machine Boring Milling Cutting Machine waterproof N Y N Y N Y 3. Advantage (1) Higher precision, better stability and smoother operation. (2) Adopting Japanese technology, double waterproof design structure, isolating cutting fluid and dust in production and processing, ensuring the good condition of the spindle head in actual work.( Waterproof function is only available on some models,Please choose the right model according to your needs) (3) The main shaft housing is cast in high-tough cast iron. After manual and natural double aging treatment, it is wear-resistant and not easily deformed. 4. Benefits for you (1) Using better manufacturing technology, bring you a higher quality and more perfect experience. (2) Excellent service, a variety of models to meet your needs. 5. Application area This series of power heads is mainly suitable for drilling, boring and other work occasions. 6. Technical Support All Products from the factory will be provided for one year warranty after sales and lifetime technical support.
