11° X 1/2″ Dovetail Router Bit – 1/4″ Shank – Yonico 14811q
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Yonico |
| Type | Router Bit |
| Application | Cutting |
| Model | 14811q |
| MPN | 14811q |
| Material | Carbide |
| Item Diameter | 1/2" |
| Item Width | 1/2" |
| Item Length | 2-3/8" |
| Suitable For | Router Tool |
| Manufacturer Warranty | Lifetime |
| Manufacturer | Yonico |
| BrandName | Yonico |
| Voltage | N/A |
11° X 1/2" Dovetail Router Bit - 1/4" Shank - Yonico 14811q Click images below to enlarge Brand: Yonico Brand New Item#: 14811q Ships Fast This dovetail bit has a cutting diameter of 1/2", and angle of 11° and a cutting height of 1/2". The bearing on the shank is 1/2" in diameter and the shank is 1/4" in diameter. Number of Bits Shank Diameter 1/4" Radius Degrees 11° Cutting Diameter 1/2" Cutting Depth Cutting Length 1/2" Largest Diameter 1/2" Overall Length 2-3/8" Number of Flutes 2 Bit Construction Carbide Tipped Design Application Coating Flute Angle Mortising Height Minimum Stock Thickness Maximum Stock Thickness Bearing Height Bearing Inner Diameter Bearing Outer Diameter Description The dovetail is probably the most recognizable of all woodworking joints. A dovetail joint is self-aligning and interlocking. There are numerous versions of the dovetail joint, including half blind dovetails, through dovetails, mitered dovetails and sliding dovetails. All of these variations are common in casework and drawer construction. A single dovetail bit can make almost any kind of dovetail, depending on the desired size. You'll need a jig to make most dovetail joints, as well as a guide bushing for your router. Check the instructions with your dovetail jig to select a bit with the appropriate angle, which will usually be somewhere between 7 and 14 degrees. We are the only authorized Yonico distributor on eBay. While you might see other "yellow" router bits being sold, the Yonico brand is manufactured in their american owned exclusive factory and does not produce products for any other brand. Free shipping to anywhere in the continental USA. Most orders go out the next business day. That means that your order will be at your door in no time. We ship to nearly every location on earth at very competitive rates and your package also gets to you quick. We have been a superior seller for over a decade. Our 40,000+ reviews give you the assurance that our quality and service is right at the top.
